CAT6A U/FTP Shielded LAN Cable 10Gbps Solid Copper LSZH PVC Purple for Data Centers

Brand Name : ITI-LINK

Model Number : ITI-C6AU-019

Certification : UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS

Place of Origin : SHENZHEN

MOQ : 1000pcs

Price : 50$-100$

Payment Terms : T/T

Supply Ability : 1500pcs/day

Delivery Time : 15-45 Days

Packaging Details : Wooden shaft packaging 32*22*12cm Outer box size： 37*37*24cm

Frequency : 500MHz

Cable Type : UFTP

Category : CAT6A

Jacket Color : Purple

Conductor Size : 23 AWG

Conductor Material : Solid Oxygen-Free Copper

Jacket Material : PVC/LSZH

Application : Data Center & Industrial Network Cable

Contact Now

CAT6A U/FTP Shielded LAN Cable 10Gbps Solid Copper LSZH PVC Purple for Data Centers
Product Overview

The ITI-LINK ITI-C6AU-019 CAT6A U/FTP Cable is a high-performance shielded LAN cable designed for demanding network environments. Built with solid oxygen-free copper conductors and U/FTP shielding, it ensures reliable high-speed data transmission.

Performance

Supporting up to 10Gbps data rates and 500MHz bandwidth, this CAT6A UFTP cable significantly reduces crosstalk, EMI and signal loss, making it ideal for data centers and industrial networks.

Structure & Materials

Each twisted pair is individually wrapped with aluminum foil (U/FTP), combined with solid copper conductors for low attenuation. The LSZH PVC jacket enhances fire safety while maintaining mechanical durability. The purple color allows easy cable identification.

Application Value

Designed for high-density cabling systems, this shielded LAN cable performs reliably in data centers, industrial Ethernet, power facilities and 5G infrastructure.

Brand Trust

ITI-LINK focuses on professional network cabling solutions, delivering stable quality and performance trusted by global engineering and industrial users.

Technical Specifications
Construction Item Description Electrical Property
Conductor
Material: Bare Solid Copper (elongation: 19-24%)
OD: 23 AWG		 Conductor Resistance at 20°C: ≤ 9.5 Ω / 100m
Resistance unbalance within a pair: ≤ 5%
Insulation
Material: HDPE 8303
OD: 1.01 ± 0.01 mm
Average THK: 0.22 mm
Color: White with colored stripes		 Insulation Resistance at 20°C: >1500 MΩ / 100m
Mutual capacitance: 5600 pF / 100m MAX
Capacitance unbalance: ≤ 160 pF / 100m
Characteristic impedance: 100 ±15 Ω
Dielectric Strength: No breakdown
Pair Twist
Lay & Direction: Various specifications per pair		 Mechanical Property
Insulation elongation before aging: ≥ 300%
Tensile strength before aging: ≥12 MPa
Elongation after aging: ≥ 150%
Tensile strength after aging: ≥10.5 MPa
Jacket
Material: PVC, Rated 60 or 75℃
Hardness: 81 ±3
OD: 6.0 ± 0.2
Average THK: 0.55~0.60
Color: Purple		 Jacket elongation before aging: ≥ 150%
Tensile strength before aging: ≥ 13.5 MPa
Elongation after aging: ≥ 125%
Tensile strength after aging: ≥ 12.5 MPa
Applications
  • Data center structured cabling systems
  • Industrial Ethernet and automation networks
  • 5G base stations and telecom infrastructure
  • Power plants and electrical control systems
  • Commercial buildings and enterprise networks
  • High-EMI environments requiring shielded LAN cable
